Doughty Clamps & Couplers

Doughty Engineering has manufactured stage lighting clamps and rigging hardware in the UK since 1985. Their stage rigging clamps are the industry standard for theatre, TV studios, concert touring and events. TÜV approved, CE marked, and stamped with SWL on every unit.

MTN Shop stocks the complete Doughty clamp range: hook clamps, half couplers, quick trigger clamps, small tube clamps, large tube clamps, boom arms, girder clamps and the Doughty-exclusive Twenty Clamp. Every Doughty clamp is available individually or in multi-packs for production houses and venues.

Doughty Clamps & Couplers - MTN Shop UK
Loading…

132 products

View

Doughty Clamps & Couplers – Product list

Doughty Stage Lighting Clamps and Couplers

At MTN Shop UK we stock the complete range of Doughty Engineering stage lighting clamps and rigging hardware. With 40 years of UK manufacturing experience behind every product, combined with our fast UK dispatch and competitive prices, you will not find a better stocked Doughty clamp supplier.

Not Sure Which Stage Clamp You Need?

  • Hook Clamps: steel truss clamp for general stage use. 20mm to 75mm tube. Affordable and stamped with SWL.
  • Half Couplers: aluminium wrap-around clamp for 48mm to 63mm tube. Higher SWL and better truss protection than a hook clamp.
  • Quick Trigger Clamps: one-person rigging of heavy fixtures at any point on a truss, no obstruction from cross webs.
  • Small Tube Clamps (Atom): for 25mm to 38mm tube. Ideal for decorative truss, stand centre tubes and studio bars.
  • Large Tube Clamps (Mammoth): for 60mm to 63mm tube. Heavy-duty aluminium, SWL up to 500kg.
  • Girder Clamps: for structural steel I-beams, marquee frames and ceiling grid hangers. No drilling required.
  • Boom Arms: aluminium and steel boom arms for side-lighting from a vertical boom pole or tank trap.

Safety and Certifications

Every Doughty clamp sold by MTN Shop UK is independently TÜV certified and CE marked. The Safe Working Load is stamped directly onto every unit so it is visible at the rigging point during installation and inspection. When selecting a clamp, always calculate the total suspended load including the fixture, cable and any attached accessories, and ensure the clamp SWL exceeds that total. A secondary safety bond must always be used when rigging any fixture overhead, regardless of clamp type. If you are unsure which clamp is right for your application, contact our team before ordering.

Frequently Asked Questions

Doughty clamps are used to attach stage lighting fixtures, speakers and moving heads to lighting bars, scaffold tubes and truss in theatre, film, TV and live events. Doughty Engineering has manufactured stage rigging clamps in the UK since 1985. All clamps are TÜV certified and CE marked.
A hook clamp attaches to a tube by hooking over it and is secured with a single bolt. A half coupler wraps fully around the tube for a greater grip. Hook clamps are faster to fit and suitable for most standard applications. Half couplers are preferred for heavier loads or where a hook clamp might twist under the load direction.
Most Doughty clamps fit 48mm to 51mm tube, the industry standard for stage lighting bars and scaffold tube. The Atom range covers 25mm to 38mm and the Mammoth range covers 60mm to 63mm. Steel hook clamps are also available from 20mm to 75mm.
SWL stands for Safe Working Load, the maximum load a clamp is certified to support. Every Doughty clamp has its SWL stamped onto the body so it is visible at the rigging point. Always use a secondary safety bond when rigging any fixture overhead.
Yes. All Doughty clamps and couplers are independently tested and TÜV certified to the relevant EN standards for entertainment rigging hardware. Every clamp is also CE marked and has its Safe Working Load stamped directly onto the product.
