Yale Hydraulic Power Pumps

Light-weight, yet powerful two-stage pumps, are specifically designed for maintenance and repair jobs.

Operating pressure max. 700 bar, two-stage design, a motor start is via a remote pendant control (1.8m) with push-button operation low voltage control.

Note: pressure gauge not included


Operation of the power pump PY-04/2/5/2M:

The 2/2-way manual valve operates together with a pilot operated unloading valve, so that the two-valve positions result in the following two control possibilities:

  • Cylinder holds pressure after motor stop.
  • Cylinder automatically retracts after motor stop.
Model Control valve operation Max. operating pressure (bar) No load stroke l/min up to 30 bar Under load stroke l/min up to 700 bar Usable reservoir volume (L) Connecting value Cable remote control (m) Weight, without oil, approx. (kg)
PY-04/2/5/2 M Manual 700 4.0 0.23 5 0,35 kW – 230 V-1Ph 1.8 24
PY-04/2/5/4 M Manual 700 4.0 0.23 6.5 0,35 kW – 230 V-1Ph 1.8 24
PYE-03/3/10/3 M Manual 700 0.3 0.3 10 0,35 kW – 400 V-3Ph 1.8 35
PYE-03/3/10/4 M Manual 700 0.3 0.3 10 0,35 kW – 400 V-3Ph 1.8 35
